Audio
|
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
|
LAN
|
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
|
•Stavka
|
- Dragon RTL8125BG |
|
•Stavka
|
- Supports Dragon 2.5G LAN Software |
|
•Stavka
|
- Smart Auto Adjust Bandwidth Control |
|
Visual Network Usage Statistics
|
- Optimized Default Setting for Game, Browser, and Streaming Modes |
|
CPU:
|
- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* |
|
Chipset:
|
- 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode* |
|
•Stavka
|
- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
|
•Stavka
|
- 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
|
•Stavka
|
* PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors. |
|
•Stavka
|
If M2_3 is occupied, PCIE2 will be disabled. |
|
CPU:
|
- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* |
|
•Stavka
|
- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* |
|
Chipset:
|
- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode* |
|
•Stavka
|
- 1 x Ultra M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen3x4 (32 Gb/s) mode* |
|
•Stavka
|
- 2 x SATA3 6.0 Gb/s Connectors |
|
•Stavka
|
ASMedia ASM1061: |
|
* Supports NVMe SSD as boot disks
|
M2_1 is the first priority for M.2 installation. |
|
•Stavka
|
M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors. |
|
•Stavka
|
M2_2 will run at Gen4x4 with 9000 and 7000 series processors, Gen4x4 with 8000 (Phoenix 1) series processors and Gen4x2 with 8000 (Phoenix 2) series processors. |
|
•Stavka
|
If SATA3_1 or SATA3_2 is occupied, M2_4 will downgrade to Gen3x2 mode. |
|
RAID
|
- Supports RAID 0 and RAID 1 for SATA storage devices |
|
•Stavka
|
- Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices |
|
CPU:
|
- 1 x USB 3.2 Gen2 Type-C (Rear) |
|
•Stavka
|
- 1 x USB 3.2 Gen1 Type-C (Rear) |
|
•Stavka
|
- 2 x USB 3.2 Gen1 Type-A (Rear (USB32_1 and USB32_2)) |
|
Chipset:
|
- 1 x USB 3.2 Gen2x2 Type-C (Front) |
|
•Stavka
|
- 4 x USB 3.2 Gen1 Type-A (2 Rear (USB32_3 and USB32_4), 2 Front) |
|
•Stavka
|
- 9 x USB 2.0 (6 Rear, 3 Front) |
|
•Stavka
|
* All USB ports support ESD Protection |
|
3 x Addressable LED Headers**
|
- 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)*** |
|
•Stavka
|
- 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)*** |
|
•Stavka
|
- 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** |
|
•Stavka
|
- 1 x 24 pin ATX Power Connector |
|
•Stavka
|
- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) |
|
1 x Front Panel Audio Connector
|
- 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) |
|
•Stavka
|
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
|
•Stavka
|
- 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) |
|
•Stavka
|
* Supports in total up to 12V/3A, 36W LED Strip |
|
•Stavka
|
** Support in total up to 5V/3A, 15W LED Strip |
|
•Stavka
|
*** CPU_FAN1 supports the fan power up to 1A (12W). |
|
•Stavka
|
CPU_FAN2, CHA_FAN1~4 and AIO_PUMP support the fan power up to 3A (36W). |
|
•Stavka
|
CPU_FAN2, CHA_FAN1~4 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use. |
|
1 x HDMI Port
|
- 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) |
|
•Stavka
|
- 1 x USB 3.2 Gen1 Type-C Port (DP-alt mode supports DP1.4a) |
|
•Stavka
|
- 4 x USB 3.2 Gen1 Type-A Ports |
|
•Stavka
|
- 6 x USB 2.0 Ports |
|
•Stavka
|
- 1 x RJ-45 LAN Port |
|
1 x BIOS Flashback Button
|
- HD Audio Jacks: Line in / Front Speaker / Microphone |
|
Software
|
- ASRock Motherboard Utility (A-Tuning) |
|
•Stavka
|
- ASRock Dragon 2.5G LAN Software |
|
ASRock Instant Flash
|
*These utilities can be downloaded from ASRock Live Update & APP Shop. |
|
2 x SATA Data Cables
|
- 1 x Screw for M.2 Socket |
|
Form Factor
|
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
|
OS
|
- Microsoft Windows® 10 64-bit / 11 64-bit |
